The Datasensing S60 is a "One for All" compact photoelectric sensor series housed in a standardized 50x50x15 mm ABS/PMMA cubic case, available across multiple optic functions with NPN or PNP output and cable or rotatable M12 connection. The representative S60-PA-5-M08-PH is a red-LED background-suppression model with an adjustable sensing distance up to 200 mm, teach-in setting, PNP light/dark-selectable output and a 500 µs response time. It operates from 10 to 30 VDC with no-load current of less than 40 mA, is rated IP67 and works from -25 to +55 °C. The series carries CE and cULus approvals.
Brand
Datalogic / Datasensing
Sensor type
Photoelectric (cubic compact sensor)
Sensing method
Background suppression (series also offers retroreflective, diffuse, contrast and luminescence variants)
Light source
Red LED
Range / distance
Up to 200 mm (adjustable, background-suppression M08 variant)
Response time
500 µs (0.5 ms)
Output type
PNP, light/dark selectable (NPN versions also available)
Supply voltage
10 to 30 VDC
Connection
M12 connector (rotatable straight/right-angle; cable versions also available)
The Datasensing S60-PA-5-M08-PH is a compact photoelectric sensor, not an imaging device, so in a vision cell its job is to detect presence or position and hand off a clean trigger or gating signal. The sensing principle here is background suppression with a red-LED emitter: the sensor uses the geometry of the reflected spot to decide whether a target sits inside a taught distance window, returning a switched output rather than an analog reading. The adjustable range reaches up to 200 mm and is set via teach-in, which means you point the sensor at the part, teach the cutoff, and any surface beyond that distance is ignored regardless of how shiny or dark it is. That distance-based discrimination is the key difference from a plain diffuse sensor and is what makes it reliable for catching parts against a conveyor belt, a fixture, or a busy machine background that would otherwise cause false triggers.
Electrically it is built to drop straight into a 24 V control environment. It runs on 10 to 30 VDC, draws less than 40 mA no-load, and delivers a PNP switched output that is light/dark selectable, so you choose whether the output asserts on target-present or target-absent without rewiring. The 500 us (0.5 ms) response time is fast enough to gate a camera or strobe on moving product at typical conveyor and indexing speeds, and the M12 connection (rotatable straight or right-angle, with cable variants also offered) keeps wiring serviceable and lets you orient the connector to fit tight mounting brackets. For a machine-vision integrator the practical pattern is to wire the PNP output into a camera trigger input or a PLC/controller input that then fires the acquisition and lighting together.
Mechanically the unit is a standardized 50 x 50 x 15 mm cubic case with an ABS/PMMA body and a PMMA optical front, rated IP67 and specified from -25 to +55 degC (without freezing). The slim 15 mm depth and flat cube format make it easy to bracket alongside cameras and lights without intruding into the field of view, and the IP67 rating means it tolerates dusty and washdown-adjacent packaging or logistics environments. CE and cULus approvals are carried across the series. Because the S60 is a 'one for all' family sharing this case across background-suppression, retroreflective, diffuse, contrast and luminescence optics, designing in this variant also gives you a drop-in path to swap sensing methods later from the same footprint and wiring.
Best for
Triggering a machine-vision camera or strobe when a part enters the inspection station, using the 500 us response time to gate acquisition on moving product
Detecting product presence against a conveyor belt or fixture in packaging lines, where background suppression rejects the belt or machine frame beyond the taught 200 mm window
Part-in-place and position confirmation in logistics sortation, sending a clean PNP signal to a PLC or vision controller
Counting or indexing items on a conveyor where consistent, distance-based detection is needed regardless of target color or gloss
Replacing diffuse sensors that false-trigger on reflective backgrounds, by using the adjustable teach-in cutoff to ignore everything past the set distance
Selection notes
This is a switching trigger/presence sensor, not a measurement device. The background-suppression variant gives a single PNP switched output, not an analog distance reading; if you need a continuous position or displacement value this part is not the right tool.
Confirm the 200 mm maximum adjustable range covers your standoff with margin, and set the teach-in cutoff comfortably ahead of the background; background suppression discriminates by distance, so leave room between the nearest target face and the surface you want to ignore.
Match the output to your input card: it is PNP and light/dark selectable. NPN versions exist in the series, so specify the correct polarity for your camera trigger or PLC input, and budget for the under-40 mA no-load current plus your load within the 10 to 30 VDC supply.
Plan the M12 orientation early. The connector is rotatable straight or right-angle and cable versions are available, which helps in tight brackets next to a camera and lens; pick the variant that keeps the cable clear of the field of view.
Check environmental limits for your line: IP67 and -25 to +55 degC (without freezing) suit dusty or washdown-adjacent packaging and logistics, but verify against any freezer, high-heat, or full-submersion conditions before designing in.
Specifications: General
Brand
Datalogic / Datasensing
Sensor type
Photoelectric (cubic compact sensor)
Specifications: Performance
Range / distance
Up to 200 mm (adjustable, background-suppression M08 variant)
Response time
500 µs (0.5 ms)
Specifications: Interface
Connection
M12 connector (rotatable straight/right-angle; cable versions also available)
Specifications: Electrical
Supply voltage
10 to 30 VDC
Specifications: Environment
Operating temperature
-25 °C to +55 °C (without freezing)
IP rating
IP67
Specifications: Sensing
Sensing method
Background suppression (series also offers retroreflective, diffuse, contrast and luminescence variants)
Light source
Red LED
Specifications: Output
Output type
PNP, light/dark selectable (NPN versions also available)
Specifications: Mechanical
Housing material
ABS/PMMA body with PMMA optical front
Dimensions
50 x 50 x 15 mm
Applications this camera is commonly selected for. Open one to see the full recommended hardware and approach.
1. Install the IMPACT Software Suite and connect the camera
Install the IMPACT Software Suite on your PC, which provides both the configuration/viewer tools and the SDK. For a GigE Vision model (E100, M or U series), connect it to a dedicated NIC and, for USB3 models, use a certified USB3 cable and port. Power the camera and confirm it enumerates.
2. Bring the camera online and verify the link
For GigE Vision, put the camera and the host NIC on the same subnet (a static IP on the camera matching the NIC range is the most reliable starting point); for USB3, confirm the device is recognized. Open the IMPACT viewer/device tool, discover the camera, and verify a stable connection before streaming. Enabling jumbo frames on the NIC helps GigE throughput.
3. Set exposure, gain and trigger, then grab a first image
In the IMPACT tools, start a live stream and adjust exposure and gain until the image is well-lit without saturation; set white balance on color models. Begin in free-run (continuous) mode to confirm imaging, then switch to hardware or software trigger as your application requires. Capture and save a reference image once the scene looks correct.
4. Build a vision tool or move to the SDK/API
Use the IMPACT point-and-click vision tools to assemble an inspection, or use the IMPACT SDK to access the camera and results programmatically and feed them into your HMI/PLC application. As these are GenICam/GenTL-compliant devices, you can alternatively drive them from any GenICam-compliant third-party vision library if your pipeline standardizes on one.
5. Route the stable feed to deep-learning inspection (optional)
Once you have a stable, repeatable image, the feed can be sent to a deep-learning inspection platform such as Rosepetal for defect detection or classification tasks that go beyond rule-based tooling. Keep lighting, optics and trigger timing fixed so the images reaching the model stay consistent.
Frequently asked questions
No. This S60-PA-5-M08-PH is a background-suppression photoelectric sensor with a switched PNP output that is light/dark selectable. It tells you whether a target is inside the taught distance window (up to 200 mm), not a continuous numeric distance, so it is used as a presence/trigger device rather than a measurement sensor.
Its response time is 500 us (0.5 ms), which is fast enough to gate camera acquisition or a strobe on moving product at typical conveyor and indexing speeds. You wire the PNP output to the camera trigger input or to a controller that fires the acquisition and lighting.
The background-suppression M08 variant has an adjustable sensing distance up to 200 mm, set by teach-in. You teach the cutoff so the sensor detects targets nearer than the taught distance and ignores anything beyond it, such as the conveyor belt or machine frame.
It runs on 10 to 30 VDC with a no-load current under 40 mA and connects via a rotatable M12 connector (cable versions also available). The housing is a 50 x 50 x 15 mm cube with an ABS/PMMA body and a PMMA optical front, rated IP67 and rated for -25 to +55 degC (without freezing), and the series carries CE and cULus approvals.
Yes. The S60 is a 'one for all' series sharing the same 50 x 50 x 15 mm case. NPN output versions are available alongside this PNP unit, and the family also offers retroreflective, diffuse, contrast and luminescence optics, so you can change polarity or sensing method while keeping the same footprint and mounting.
