Datasensing S85-MH-5-Y03-OOI
S85-MH-5-Y03-OOI
The S85-MH-5-Y03-OOI is a compact cubic laser distance sensor using Time-of-Flight (TOF) technology with a Class 2 red laser (658 nm) for non-contact measurement up to 10 m without a prismatic reflector. It delivers 1 mm resolution, 7 mm accuracy, and 1 mm repeatability, configurable via push-buttons with scalable 4–20 mA analog output plus two NPN/PNP digital switching outputs. The sensor is housed in a zinc alloy (Zamak) enclosure rated IP67, connecting via a 5-pin M12 plug, and operates from 10–30 VDC with a maximum power consumption of 2.8 W.
- Brand
- Datalogic / Datasensing
- Sensor type
- distance
- Sensing method
- tof
- Range / distance
- 10000.0 mm
- Output type
- NPN/PNP/ANALOG
- Light source
- red_laser
- Response time
- 30.0 ms
- Supply voltage
- 24 VDC ±20%
- Connection
- M12 5-pin
- IP rating
- ip67
- Dimensions
- 37 × 62 × 60 mm
- Operating temperature
- -15 to +50 °C
| Brand | Datalogic / Datasensing |
|---|---|
| Sensor type | distance |
| Range / distance | 10000.0 mm |
|---|---|
| Response time | 30.0 ms |
| Connection | M12 5-pin |
|---|
| Supply voltage | 24 VDC ±20% |
|---|---|
| Power consumption | 2.8 W |
| IP rating | ip67 |
|---|---|
| Operating temperature | -15 to +50 °C |
| Sensing method | tof |
|---|---|
| Light source | red_laser |
| Output type | NPN/PNP/ANALOG |
|---|
| Dimensions | 37 × 62 × 60 mm |
|---|---|
| Housing material | Zinc alloy (Zamak) with PMMA lens |
