Basler Standard Light Dome-300OD-Blue
Standard Light Dome-300OD-Blue
The Basler Standard Light Dome-300OD-Blue is a 300 mm outer-diameter dome light designed for shadow-free bright-field illumination of reflective and curved surfaces. It features an internal LED controller supporting continuous (voltage-controlled) and triggered (current-controlled) operation modes, and is compatible with the Basler SLP Strobe Controller for high-power strobe use up to 4800 mA at 10% duty cycle. The unit operates at 24 VDC with 22 W power consumption, carries an IP54 protection rating, and connects via a 4-pin M8 socket. Housed in black anodized aluminum with a plastic dome diffuser, it measures 350 × 350 × 179 mm and weighs 1950 g.
- Lighting type
- Dome
- Color / wavelength
- 465 nm
- Working distance
- 1–30 mm
- Inner diameter
- 300 mm
- Illuminated area
- Ø 300 mm
- Available wavelengths
- Blue (465 nm), Red (625 nm), White (5000 K), Infrared (850 nm)
- Power consumption
- 22 W
- Supply voltage
- 24 VDC ±5%
- IP rating
- IP54
- Dimensions
- 350 × 350 × 179 mm
- Weight
- 1950 g
- Housing material
- Black anodized aluminum with plastic dome
| Lighting type | Dome |
|---|
| Color / wavelength | 465 nm |
|---|---|
| Working distance | 1–30 mm |
| Available wavelengths | Blue (465 nm), Red (625 nm), White (5000 K), Infrared (850 nm) |
| Power consumption | 22 W |
|---|---|
| Supply voltage | 24 VDC ±5% |
| IP rating | IP54 |
|---|---|
| Operating temperature | 10–30 °C (up to 45 °C with heat dissipation) |
| Inner diameter | 300 mm |
|---|---|
| Illuminated area | Ø 300 mm |
| Dimensions | 350 × 350 × 179 mm |
|---|---|
| Weight | 1950 g |
| Housing material | Black anodized aluminum with plastic dome |
