Basler Standard Light Bar-90x100-Blue
Standard Light Bar-90x100-Blue
The Basler Standard Light Bar-90x100-Blue is an LED area bar light from the Basler Standard product line providing direct, homogeneous blue illumination over a 90 x 100 mm emitting surface at a peak wavelength of 465 nm. It operates on 24 VDC and consumes 17 W (900 mA in current-controlled mode), with an internal LED controller supporting both continuous and triggered (strobe) operating modes down to 100 µs pulse width. The housing is black anodized aluminum with a PMMA cover, rated IP54, and connects via an M8 4-pin male socket. Recommended working distance is 10–400 mm.
- Lighting type
- Area Bar Light
- Color / wavelength
- Blue
- Available wavelengths
- 465 nm (Blue)
- Illuminated area
- 90 mm x 100 mm
- Working distance
- 10–400 mm
- Power consumption
- 17 W / 900 mA
- Supply voltage
- 24 VDC ±10%
- IP rating
- IP54
- Emission angle
- Direct
- Driver technology
- Internal LED controller (current or voltage controlled)
- Dimensions
- 99 x 110 x 23 mm (H × W × D)
- Weight
- 370 g
| Lighting type | Area Bar Light |
|---|
| Color / wavelength | Blue |
|---|---|
| Available wavelengths | 465 nm (Blue) |
| Working distance | 10–400 mm |
| Emission angle | Direct |
| Power consumption | 17 W / 900 mA |
|---|---|
| Supply voltage | 24 VDC ±10% |
| Driver technology | Internal LED controller (current or voltage controlled) |
| IP rating | IP54 |
|---|---|
| Operating temperature | 10–30 °C (up to 45 °C with heat dissipation) |
| Illuminated area | 90 mm x 100 mm |
|---|
| Dimensions | 99 x 110 x 23 mm (H × W × D) |
|---|---|
| Weight | 370 g |
| Housing material | Black anodized aluminum with PMMA cover |
