LENS-12.5 2/3" 5MP W/L M49x0.75
927-HF12.5SA-1
The 927-HF12.5SA-1 is a Fujinon HF12.5SA-1 fixed focal length lens distributed by Datasensing (Datalogic), offering a 12.5 mm focal length, f/1.4–f/22 aperture range, and an 11 mm image circle covering 2/3" sensors at up to 5 MP resolution. The lens features manual focus and manual iris controls, both secured by locking screws to prevent unintentional adjustment in vibration-prone industrial environments. Its spectral range spans 400–1000 nm (visible to NIR), with a rear-focusing system and low TV distortion of -0.08%. Minimum object distance is 100 mm, with a back focal length of 16.07 mm.
- Focal length
- 12.5 mm
- Lens mount
- C-mount
- Aperture (f-number)
- f/1.4 – f/22
- Image circle / max sensor
- 11 mm
- Optical resolution
- 5 MP
- Telecentric
- No
- Working distance
- 100 mm – ∞
- Weight
- 295 g
- Dimensions
- 51 mm × 68.5 mm
- Operating temperature
- -10 to +50°C
| Focal length | 12.5 mm |
|---|---|
| Lens mount | C-mount |
| Aperture (f-number) | f/1.4 – f/22 |
| Image circle / max sensor | 11 mm |
| Optical resolution | 5 MP |
| Telecentric | No |
| Working distance | 100 mm – ∞ |
| Operating temperature | -10 to +50°C |
|---|
| Weight | 295 g |
|---|---|
| Dimensions | 51 mm × 68.5 mm |
