Is DCM Sistemes PRY0504A compatible with Rosepetal?

Yes. It is marked as Rosepetal-ready: it is suitable for AI-based visual inspection. We can validate your case with sample images.

Which lens and lighting do I need?

It depends on the field of view, the working distance and the surface. We help you select the right lens + lighting combination.

Name: DCM Sistemes PRY0504A
Brand: DCM Sistemes
SKU: dcm-sistemes-pry0504a
Availability: PreOrder

PRY0504A

DCM Sistemes PRY0504A — bar light, 43x45mm active area, wavelengths 365nm 400nm 470nm 525nm 630nm 850nm W00, >50mm working distance.

Specifications: General
Brand	DCM Sistemes
Lighting type	bar

Specifications: Optical
Working distance	>50mm
Available wavelengths	365nm 400nm 470nm 525nm 630nm 850nm W00

Specifications: Electrical
Mode	Continuo Potenciado Estrobo iBlueDrive
Driver technology	Continuo Potenciado Estrobo iBlueDrive

Specifications: Mechanical
Dimensions	56x46.5x18mm

Specifications: Geometry
Illuminated area	43x45mm
