Fixed 50 mm F/2.8 F-mount lens designed for Super 35 mm sensors up to 45 MP with a 32 mm image circle, optimized for 3.2 µm pixel pitch cameras.
- Rosepetal compatible
- Recommended by AIS Vision
On request
F-mount / large-format lenses
42 results
Basler Standard F-mount fixed focal length lens with 75 mm focal length, F2.8–F22 aperture range, and 32 mm image circle covering Super 35 format sensors up to 45 MP resolution.
- Rosepetal compatible
- Recommended by AIS Vision
On request
Datalogic / DatasensingDatasensing LENS-50-FM-M52 x0.75 — 50 mm Large Format F-Mount LensLENS-50-FM-M52 x0.75A 50 mm fixed focal length, F-mount, large-format machine vision lens covering a 43.3 mm image circle with an aperture range of F2.8–16 and M52x0.75 filter thread.
- Rosepetal compatible
- Recommended by AIS Vision
On request
A 20 mm fixed focal length, large-format machine vision lens with M42 x P1 mount, 30 mm image circle, and manual focus/aperture for visible-spectrum industrial imaging.
- Rosepetal compatible
- Recommended by AIS Vision
On request
25 mm fixed focal length large-format M42-mount lens designed for 4K line scan cameras with a 30 mm image circle and low distortion.
- Rosepetal compatible
- Recommended by AIS Vision
On request
28mm focal length, F/4 aperture, M42-mount large-format lens from iRAYPLE's 4K line-scan series supporting a 30mm image circle.
- Rosepetal compatible
- Recommended by AIS Vision
On request
35mm F-mount large-format line scan lens supporting up to Φ30mm image circle, designed for 4K line scan cameras with 7µm pixel pitch.
- Rosepetal compatible
- Recommended by AIS Vision
On request
iRAYPLE F32-5035-M43 industrial lens.
- Rosepetal compatible
- Recommended by AIS Vision
On request
40 mm f/2.8 large-format line-scan lens with a 43 mm image circle and M42×P1 mount, designed for 4K line-scan cameras with 7 µm pixel pitch.
- Rosepetal compatible
- Recommended by AIS Vision
On request
A 60mm focal length, F3.5, M58-mount large-format industrial machine vision lens designed for up to 65MP sensors with a 46mm image circle.
- Rosepetal compatible
- Recommended by AIS Vision
On request
40mm F4.0 large-format M72-mount line scan lens with Φ60mm image circle, designed for 8K line scan cameras with 7μm pixel sensors.
- Rosepetal compatible
- Recommended by AIS Vision
On request
A 60mm focal length large-format M72-mount line scan lens designed for 8K resolution line scan cameras with 7 µm pixel pitch sensors, featuring low distortion and a 60mm image circle.
- Rosepetal compatible
- Recommended by AIS Vision
On request
60mm fixed-aperture F5.6 F-mount lens with Φ60mm image circle, designed for 8K line scan cameras with 7µm pixel size.
- Rosepetal compatible
- Recommended by AIS Vision
On request
90mm fixed focal length M72-mount large-format lens designed for 16K line scan cameras, covering a 64mm image circle at F4.0–F16.
- Rosepetal compatible
- Recommended by AIS Vision
On request
55mm focal length, F4.5 aperture large-format lens with Φ67mm image circle and M72 mount supporting 151MP resolution sensors.
- Rosepetal compatible
- Recommended by AIS Vision
On request
80 mm fixed-focal large-format line-scan lens with M72×P0.75 mount, Φ80 mm image plane, and F4.0–22 aperture, designed for 8K line-scan cameras with 7 µm pixels.
- Rosepetal compatible
- Recommended by AIS Vision
On request
28 mm fixed focal length F-mount large-format lens covering 43.3 mm sensor diagonal, with M72×0.75 filter thread, aperture F/2.8–16, and 200 lp/mm center resolution.
- Rosepetal compatible
- Recommended by AIS Vision
On request
Omron / SentechOmron / Sentech VS-L8540/M42-10 — 85 mm F4.0 Large-Format Line-Scan Macro Lens (M42 Mount)3Z4S-LE VS-L854085 mm f/4.0 large-format line-scan macro lens with M42 mount, φ50 mm image circle, and 0.00% TV distortion, designed for Omron FH-S 12 MP M42-mount cameras.
- Rosepetal compatible
- Recommended by AIS Vision
On request
Omron / SentechOmron 3Z4S-LE VS-L10028/M42-10 — 100 mm F2.8 M42-Mount Large-Format Lens3Z4S-LE VS-L10028100 mm f/2.8 fixed-focal-length M42-mount lens for large-sensor Omron FH-S series cameras, covering up to 1.8-inch CCD format with φ45 mm image circle and 0.05× to 0.3× magnification range.
- Rosepetal compatible
- Recommended by AIS Vision
On request
Non-telecentric 0.3× fixed-magnification C-mount macro lens for machine vision, covering up to 2/3" sensors with 0% TV distortion and 184.8 mm working distance.
- Rosepetal compatible
- Recommended by AIS Vision
On request
Fixed 0.5x magnification, non-telecentric C-mount macro lens with 43.9 mm focal length, 126.3 mm working distance, and 0.00% TV distortion for 2/3" sensors.
- Rosepetal compatible
- Recommended by AIS Vision
On request
Omron / SentechOmron 3Z4S-LE VS-MCL50-FNO56/M42-10 — 50 mm F5.6 Vibration-Resistant M42 Lens3Z4S-LE VS-MCL50-FNO5650 mm fixed focal length, F5.6 fixed aperture, M42-mount machine vision lens with vibration and shock resistance for 1.8-inch sensors, designed for Omron 12 MP FH-S series cameras.
- Rosepetal compatible
- Recommended by AIS Vision
On request
Fixed-magnification (0.1×) non-telecentric macro C-mount lens with a 325.5 mm working distance and near-zero distortion, designed for 2/3-inch machine-vision cameras.
- Rosepetal compatible
- Recommended by AIS Vision
On request
Fixed 1.0x magnification C-mount macro lens for up to 2/3" sensors with 43.9 mm focal length, 82.4 mm working distance, and 0.00% TV distortion.
- Rosepetal compatible
- Recommended by AIS Vision
On request
Frequently asked questions
Request a technical quote
We help you choose f-mount / large-format lenses based on your application, FOV, working distance and environment.
