Datasensing Telecentric Lens 0.50x TML 1/2" M37x0.75 (933-63-074)
LENS-TC-0.50x-TML-1
The LENS-TC-0.50x-TML-1/2-M37x0.75 (part 933-63-074) is a bilateral telecentric C-Mount lens offering 0.50x magnification compatible with sensors up to 1/1.8" format (specified by Datasensing for 1/2" sensors). It delivers a fixed working distance of 120 mm (±3 mm tolerance) with an adjustable iris from f/6 to f/22 and object-side NA of 0.041. Telecentricity is guaranteed to <0.012° at 520 nm and typical distortion is <0.200%, making it suitable for dimensional measurement and gauging. The lens features BBAR coating from 425–675 nm, a non-focusing mechanical design in anodized aluminum, and we
- Brand
- Datalogic / Datasensing
- Lens mount
- c-mount
- Aperture (f-number)
- f/6-f/22
- Image circle / max sensor
- value: 8.9, display: '~8.9 mm (1/1.8" max format)', unit: 'mm'
- Telecentric
- Yes
- Magnification
- 0.5
- Working distance
- 120 mm
- Weight
- 226 g
| Brand | Datalogic / Datasensing |
|---|
| Lens mount | c-mount |
|---|---|
| Aperture (f-number) | f/6-f/22 |
| Image circle / max sensor | value: 8.9, display: '~8.9 mm (1/1.8" max format)', unit: 'mm' |
| Telecentric | Yes |
| Magnification | 0.5 |
| Working distance | 120 mm |
| Weight | 226 g |
|---|
