Datasensing LENS-TC-0.50x-TML-1/2-M37x0.75
933-63-074
The Datasensing 933-63-074 (OEM: Edmund Optics TECHSPEC SilverTL #63-074) is a double-sided telecentric lens designed for high-accuracy machine vision metrology. It provides 0.50x magnification with a fixed 120mm working distance (±3mm tolerance) and supports up to 1/1.8" sensor formats (Datasensing specifies the 1/2" format target configuration). The adjustable iris runs from f/6 to closed, yielding resolution greater than 40% MTF at 40 lp/mm (image space, f/10), depth of field of ±2.1mm at f/10, telecentricity below 0.1°, and distortion under 0.3%. Optics are BBAR coated from 425–675nm; the M37x0.75 front filter thread accepts color filters, polarizers, and illumination adapters.
- Lens mount
- C-Mount
- Magnification
- 0.50x
- Image circle / max sensor
- 8 mm (1/2" format)
- Working distance
- 120 mm (±3 mm)
- Aperture (f-number)
- f/6 – Closed (adjustable)
- Telecentric
- Yes (<0.1°)
| Lens mount | C-Mount |
|---|---|
| Magnification | 0.50x |
| Image circle / max sensor | 8 mm (1/2" format) |
| Working distance | 120 mm (±3 mm) |
| Aperture (f-number) | f/6 – Closed (adjustable) |
| Telecentric | Yes (<0.1°) |
