Datasensing LENS-28-FM-M72 x0.75

LENS-28-FM-M72 x0.75

The LENS-28-FM-M72 x0.75 is a large-format fixed focal length lens designed for machine vision cameras with up to 43.3 mm sensor diagonal coverage. It features an F-Mount interface and an M72x0.75 filter thread for optional filter attachment. The aperture range is F/2.8 to F/16, and optical resolution reaches 200 lp/mm at center and 63 lp/mm at the edge. The OEM manufacturer is Navitar (part 1-19711); Datasensing sells it as part 927-1-19711.

Brand: Datalogic / Datasensing
Lens mount: f-mount
Focal length: 28 mm
Aperture (f-number): 2.8
Image circle / max sensor: 43.3
Telecentric: No
Dimensions: 75×98 mm

Request a technical quote Talk to AIS Vision

Specifications: General
Brand	Datalogic / Datasensing

Specifications: Optical
Lens mount	f-mount
Focal length	28 mm
Aperture (f-number)	2.8
Image circle / max sensor	43.3
Telecentric	No

Specifications: Mechanical
Dimensions	75×98 mm

22 cameras are compatible with this lens.

Matched automatically by: camera mount fits the lens mount · camera sensor is covered by the lens image circle — this lens: f-mount · 43.3 image circle.

By category

All 22High-resolution cameras 11High-speed cameras 7Area scan cameras 3Line scan cameras 1

By brand

All 22Omron / Sentech 14Basler 7iRAYPLE 1

Showing 22 results

BaslerBasler boost boA4500-45cmboA4500-45cm
- Rosepetal compatible
- Recommended by AIS Vision
On request
View
BaslerBasler boost boA6500-36ccboA6500-36cc
- Rosepetal compatible
- Recommended by AIS Vision
On request
View
BaslerBasler boost boA6500-36cmboA6500-36cm
- Rosepetal compatible
- Recommended by AIS Vision
On request
View
BaslerBasler boost boA8100-16ccboA8100-16cc
- Rosepetal compatible
- Recommended by AIS Vision
On request
View
BaslerBasler boost boA8100-16cmboA8100-16cm
- Rosepetal compatible
- Recommended by AIS Vision
On request
View
BaslerBasler boost boA9344-70ccboA9344-70cc
- Rosepetal compatible
- Recommended by AIS Vision
On request
View
BaslerBasler boost V boA5120-230ccboA5120-230cc
- Rosepetal compatible
- Recommended by AIS Vision
On request
View
iRAYPLEiRAYPLE AX5A22CX060EAX5A22CX060E
- Rosepetal compatible
- Recommended by AIS Vision
On request
View
Omron / SentechOmron / Sentech Sentech FS-C4KU7DGES-F GigE Vision Color Dual Line Scan CameraFS-C4KU7DGES-F
- Rosepetal compatible
- Recommended by AIS Vision
On request
View
Omron / SentechOmron STC-CMB120ACXP-FSTC-CMB120ACXP-F
- Rosepetal compatible
- Recommended by AIS Vision
On request
View
Omron / SentechOmron STC-CMB120ACXP-T-FSTC-CMB120ACXP-T-F
- Rosepetal compatible
- Recommended by AIS Vision
On request
View
Omron / SentechOmron STC-CMB120AOPQ-FSTC-CMB120AOPQ-F
- Rosepetal compatible
- Recommended by AIS Vision
On request
View

Follow these steps to bring a Datalogic / Datasensing camera online, grab a first image, and move toward an integrated inspection.

Software: IMPACT Software Suite

1. Install the IMPACT Software Suite and connect the camera
Install the IMPACT Software Suite on your PC, which provides both the configuration/viewer tools and the SDK. For a GigE Vision model (E100, M or U series), connect it to a dedicated NIC and, for USB3 models, use a certified USB3 cable and port. Power the camera and confirm it enumerates.
2. Bring the camera online and verify the link
For GigE Vision, put the camera and the host NIC on the same subnet (a static IP on the camera matching the NIC range is the most reliable starting point); for USB3, confirm the device is recognized. Open the IMPACT viewer/device tool, discover the camera, and verify a stable connection before streaming. Enabling jumbo frames on the NIC helps GigE throughput.
3. Set exposure, gain and trigger, then grab a first image
In the IMPACT tools, start a live stream and adjust exposure and gain until the image is well-lit without saturation; set white balance on color models. Begin in free-run (continuous) mode to confirm imaging, then switch to hardware or software trigger as your application requires. Capture and save a reference image once the scene looks correct.
4. Build a vision tool or move to the SDK/API
Use the IMPACT point-and-click vision tools to assemble an inspection, or use the IMPACT SDK to access the camera and results programmatically and feed them into your HMI/PLC application. As these are GenICam/GenTL-compliant devices, you can alternatively drive them from any GenICam-compliant third-party vision library if your pipeline standardizes on one.
5. Route the stable feed to deep-learning inspection (optional)
Once you have a stable, repeatable image, the feed can be sent to a deep-learning inspection platform such as Rosepetal for defect detection or classification tasks that go beyond rule-based tooling. Keep lighting, optics and trigger timing fixed so the images reaching the model stay consistent.
